| Fingerprint capacity | 3000 |
| ID Card capacity | 10,000 Optional |
| Record capacity | 100,000 |
| Display | 3-inch TFT Screen |
| Communication | TCP/IP,RS232/485,USB (host and client) |
| Standard functions | Work code, SMS, DST, Self-Service Query, Automatic Status Switch, Built-in Battery, Multiple Verify Mode |
| Access control interfaces for | 3rd party electric lock, door sensor, exit button, Alarm, and Door Bell |
| Wiegand Signal | input & Output |
| Software | ZKTime.Net, ZKTime5.0 |
| Power supply | DC12V 3A |
| Verification Speed | ≤5 sec |
| Operating temp | 0 °C- 45 °C |
| Operating Humidity | 20%-80% |
| Dimension(W×H×D) | 211.5*159.4.2*47.8mm(Length*Width*Thickness) |
